SEA SETRONIK1 - Input Programming

SEA SYSTEMS
INSTALLATION AND USE MANUAL
CONTROL PANEL and PREWIRED SYSTEM STK1
For Electric and Hydraulic Lifts
MSTK12-GB
Rev.01
30/12/05
SETRONIK1 Pagina 38 di 54
3.14.I
NPUT PROGRAMMING:
DG0 DG1 DG2 DG3 DG4 DG5 DG6
5 00
INPUT FUNCTION
00
None
INPUTS: 01
- Safety photocells (With operators in 02 type);
- Door opening extralimit switch of the 1° and 2° operator (with
operator different from 02 type) (NC contact)
Led Term. 02
Oil thermal sensor (NC contact)
00 03
Low point pressure switch (NC contact)
01
X1 X1
04
Peak point pressure switch (NC contact)
02 (*)
X2 X2
05
Landing operation stop control (for ACVV or 3VF with old interface)
03 (*)
X3 X3
06
Operator A sticking contactor control
04 (*)
X4 X4
07
Operator B sticking contactor control
05 (*)
X5 X5
08
Fire-fighting operation with despatch to the fire-fighting floor #1
06
X6 J8.4
09
Fire-fighting operation with despatch to the fire-fighting floor #2
07 (*)
X7 J9.4
10
Preferential operation
08
X8 J2.4
11
Safety circuit control (err 19, 20)
09
X9 J2.5
12
Very close landings control (with Additional ID switch)
10
X10 J2.6
13
Very close landings control (with Additional IS switch)
11
X11 J2.7
14
High/low speed Maintenance
12
FG FG
16
Full load
13
MR MR
17
Alarm with 0094 error, Out-of-service on landing
14
TC TC
18
Additional extralimit switch in the top_Contact monitoring and 0095
error signalling
15
PST PST
19
Alarm with 0096 error, immediate out-of-service
16
MP MP
20
Alarm with 0097 error, Failed start (3VF)
21
Reserved operation
22
Hong Kong Firemen operation
23
Photocell of the operator A independent of the opening push button
(used with selective opening)
24
Photocell of the operator B independent of the opening push button
(used with selective opening)
25
Out-of-service with despatch to the programmed parking floor with
signalling of error 098
(*) = Leds and
terminals are on the
expansion card
STK1-E
26
BA1 input (NA) for panels without board STK1-E
28
Emergency operation (not with board B12E)
29
CM1 input (NC) for panels without board STK1-E
30
Doors closing limit switch for operator A (NC contact for lifts with
motors powered during the run)
31
Doors closing limit switch for operator B (NC contact for lifts with
motors powered during the run)
32
Low and peak point pressure switch (PST) (NC contact; it can be
used only on inputs X6, X9, FG, PST)
NOTE: If it isn’t specified the contacts are N.O.
