4.DIAGNOSIS
4.1.LIFT STATUS DISPLAY
The parameter value (DG3..DG6) is constantly updated in relation to the current status of
the lift.
If the Car Position is 00 (DG5, DG6), this means that the resetting operation has not been
performed.
DG0 DG1 DG2 DG3 DG4 DG5 DG6
0
0 0
CAR POSITION
0= Lift without resetting
n= Actual position ( from 1 to 12)
OPERATION STATUS
0= Floor parking
1= Doors closing for start
2= High speed motion
3= Low speed motion
4= Doors opening
5= Car still off landing
LIFT STATUS
0= Normal operation
1= Firemen operation on
2= Fire-fighting operation on
3= Preferential operation on
4= Reserved operation on
5= Safety photocell action
6= Not used
7= Out-of-service for failures at floor
8= Out-of-service for permanent failures
9= Maintenance operation on
