Secutron MR-2306-DDR User Manual

15
System Components, Sub-Assemblies & Accessories
4.6 Smart Relay Module
4.7 Input Class A converter: Six Circuits
4.8 Output Class A converter: four circuits
4.9 Output Class A converter: two circuits
Model Description
MR-2312-SR12/
MR-2312-SW12
Smart Relay Module (12 relays) with red or white
enclosure
Model Description
MR-2300-A
Input Class A converter Module (six circuits). This
module has built in Active End-of-Line resistors
Model Description
MR-2300-NC4 Output Class A converter module (four circuits)
Model Description
MR-2300-NC2 Output Class A converter module (two circuits)
MR-2300 SERIES REMOTE RELAY
BLK RED
BLK RE DBLK REDBLK REDBLK REDBLK RED
- DET1 OUT+- DET2 OUT+- DET3 OUT+- DET4 OUT+- DET5 OUT+- DET6 OUT+
- DET1 RET+- DET2 RET +- DET3 RET+- DET4 RET+- DET5 RET+- DET6 RET+
- SIG1 OUT+- SIG2 OUT+
- SIG1 RET +- SIG2 RET +
BLK RED
BLK RED
- SIG3 OUT+- SIG4 OUT+
- SIG3 RET +- SIG4 RET +
BLK RED
BLK RED
- SIG1 OUT+- SIG2 OUT+
- SIG1 RET +- SIG2 RET +
BLK RED
BLK RED
