Configuration
11.16.10City tie Polarity reversal - MR-2300-PR Relay module
The city tie or polarity reversal module is supervised for open and whether or not the MR-
2300-PR is plugged in. The relay module is supervised for whether or not it is plugged in.
If any of the modules are not plugged in, the following trouble message is generated:
Figure 56 Module missing message
If there is an open detected on the city tie output, the following trouble message is displayed:
Figure 57 Module trouble message
Note: The trouble code and info is for trained service personnel only.
"INFO" Key
CtyTie/RM312 missing
Active 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
RMxxx missing
"INFO" Key
City Tie trouble
Active 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
i
