Appendix C: Specifications
MR-2300-PR Polarity Reversal and City Tie Module
City Tie power limited / 24 VDC unfiltered / 250 mA
max / 14
Ω trip coil
Polarity Reversal power limited / 24 VDC open / 12 VDC at
3.5 mA / 8.5 mA max (shorted)
Polarity Reversal Supv. Terminal 24 VDC (normal) / -24 VDC (supervisory) / 0 V
(trouble)
Polarity Reversal Alarm Terminal 24 VDC (normal) / -24 VDC (alarm) / 0 V
(trouble)
Current Consumption standby 50 mA / alarm 300 mA (city tie in use)
/ alarm 70 mA (city tie not in use)
MR-2605-T Remote Trouble Indicator Standby 35 mA / alarm 35 mA
Table 13 FA-300 LCD System Modules and Annunciators (Continued)
MR-2300 LCD Series Modules and Annunciators

Secutron MR-2306-DDR Specifications

General

Brand	Secutron
Model	MR-2306-DDR
Category	Control Panel
Language	English
