Secutron MR-2306-DDR User Manual

82
Configuration
11.16.6Ground Fault
Figure 52 Ground Fault message
11.16.7Remote Annunciator
Troubles related to the annunciator can have two possibilities: either the main panel and
annunciator failed to communicate with each other, or an unconfigured remote annunciator is
responding to the main panel. In both the cases, the following trouble message is displayed:
Figure 53 Remote Annunciator message
Note: The trouble code and info is for trained service personnel only.
"INFO" Key
Ground Fault
Active 1/ 1
Trouble Type
EVENT
01 of 01
Trb:0x03 Info:0x0001
00:07 SAT 2000-01-01
DATE
TIME
Trouble code Trouble Info
i
RAU num mismatch
trouble 1/ 1
Trb:0x03 Info:0x0001
11:45 SAT 2003-02-03
Trouble Type
EVENT
01 of 09
DATE
TIME
"INFO" Key
Trouble code
Trouble info
