8.3 Troubleshooting
Table 7 Troubleshooting
Symptoms
(as displayed on
the LCD)
Possible Cause
Circuit Trouble
Normally when a circuit trouble occurs, the common trouble indicator will illuminate
and trouble buzzer will sound. To correct the fault, check for open wiring on that
particular circuit loop (as displayed on the LCD) or that the circuit has not been
disconnected (or bypassed). Disconnecting a Circuit will cause a system trouble (off-
normal position).
Remote Fail
Remote Fail will be indicated on the main LCD display for any failure reported by, or
failure to communicate with a remote annunciator or other remote device.
Ground Fault
This panel has a common ground fault detector. To correct the fault, check for any
external wiring touching the chassis or other Earth Ground connection.
Battery Trouble
Check for the presence of batteries and their conditions. Low voltage (below 20.4V)
will cause a battery trouble. If battery trouble condition persists, replace batteries as
soon as possible.
Common Trouble
If only a common trouble is indicated on the main panel and none of the above
troubles exist, check the following for a possible fault:
Check for any missing interconnection wiring.
Check for any Module missing that was part of the Configuration.
Check for improperly secured cabling.
