Secutron MR-2306-DDR

61
Configuration
Command Menu-->MR-2300 Config
11.3.4 Opt Zone
This menu is used to program the process type of the indicating circuits. The maximum
number of indicating circuits is four, but only those supported by the particular model will be
shown.
Command Menu-->MR-2300 Config
11.3.5 Correlation
Note: Refer to section 11.2.1 on page 55 for detailed instructions on making menu
selections.
Command Menu/MR-2300 Config/Opt. Zone
1. Type (Indicating Circuits)
4.
[X] SIL-ABLE->Default
[ ] NON SIL-ABLE
[ ] SIL-ABLE STR
[ ] NON-SIL STR
Use this menu to select the
process type of each
indicating circuit. See
section 9.4 on page 46 for
details.
Command Menu/MR-2300 Config/Correlation
1.Correlation
12.
[X] NAC-1 ->Default
[X] NAC-2 ->Default
[X] NAC-3 ->Default
[X] NAC-4 ->Default
Use this menu to correlate
initiating circuits to the
indicating circuits. By default
all the initiating circuits are
correlated to all the indicating
circuits.
i
1 NAC-1
2 NAC-2
3 NAC-3
4 NAC-4
Indicating Zone
NAC-1 Type
[X] SIL-ABLE
NAC-4 Type
[X] SIL-ABLE
Zone-1 Corr.
[X] NAC-1
Zone-12 Corr.
[X] NAC-1
