Operator control

8.2 Operator input steps

SENTRON PAC4200

System Manual, 09/2009, A5E02316180B-02

129

Displaying instantaneous values, sliding window demand values, or maximum and minimum values

F1 switches the display on.

: Display of the maximum value

: Display of the minimum value

: Display the sliding window demand

: Display the maximum value of the sliding window demand

: Display the minimum value of the sliding window demand

: Display of the instantaneous value

Reset the maximum or minimum value to the instantaneous value

F3 resets the last reached maximum/minimum value to the instantaneous value.

Switching between import, export, process and period

F1 switches between import, export, process, and period for active energy and reactive

energy. With the exception of displaying export, the same selection options exist for

apparent energy.

F1 : Display of export

: Display of import

: Display of total consumption and display of process consumption with current

consumption value and last consumption value.

: Display of the import or the export for a specific period according to on-peak

and off-peak

Calling the "MAIN MENU"

F4 calls the menu selection. The selection bar is at the last displayed measured

variable in the menu selection.
