Technical data
11.8 Labeling on the PAC RS485 expansion module
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
191
Symbol, label Explanation
(5)
General Warning Symbol
(6)
Measuring category CAT III for current and voltage inputs.
(7)
AC current.
(8)
Three-phase AC.
(9)
Protective insulation, device with protection class II.
11.8 Labeling on the PAC RS485 expansion module
Description
The graphic below shows the positioning of the label on the housing of the PAC RS485
expansion module.
3$&56
.0$0$$
;
0DGHLQ*HUPDQ\
s
Figure 11-2 PAC RS485 expansion module with type plate
(1) Type plate
