SENTRON PAC4200 - Maximum values with a time stamp and the function codes 0 x03 and 0 x04

Appendix
A.3 MODBUS
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
239
A.3.8 Maximum values with a time stamp and the function codes 0x03 and 0x04
Addressing the maximum values with a time stamp
SENTRON PAC4200 provides the maximum values listed below with a time stamp.
Table A- 15 Available measured variables: Maximum values with time stamp
Offset Number of
registers
Name Format Unit Value range Access
3001 6 Maximum Voltage a-n with Time Float + time stamp V - R
3007 6 Maximum Voltage b-n with Time Float + time stamp V - R
3013 6 Maximum Voltage c-n with Time Float + time stamp V - R
3019 6 Maximum Voltage a-b with Time Float + time stamp V - R
3025 6 Maximum Voltage b-c with Time Float + time stamp V - R
3031 6 Maximum Voltage c-a with Time Float + time stamp V - R
3037 6 Maximum Current a with Time Float + time stamp A - R
3043 6 Maximum Current b with Time Float + time stamp A - R
3049 6 Maximum Current c with Time Float + time stamp A - R
3055 6 Maximum Apparent Power a with
Time
Float + time stamp VA - R
3061 6 Maximum Apparent Power b with
Time
Float + time stamp VA - R
3067 6 Maximum Apparent Power c with
Time
Float + time stamp VA - R
3073 6 Maximum Active Power a with Time Float + time stamp W - R
3079 6 Maximum Active Power b with Time Float + time stamp W - R
3085 6 Maximum Active Power c with Time Float + time stamp W - R
3091 6 Maximum Reactive Power a (VARn)
with Time
Float + time stamp VAR - R
3097 6 Maximum Reactive Power b (VARn)
with Time
Float + time stamp VAR - R
3103 6 Maximum Reactive Power c (VARn)
with Time
Float + time stamp VAR - R
3109 6 Maximum Total Reactive Power a
(VARtot) with Time
Float + time stamp VAR - R
3115 6 Maximum Total Reactive Power b
(VARtot) with Time
Float + time stamp VAR - R
3121 6 Maximum Total Reactive Power c
(VARtot) with Time
Float + time stamp VAR - R
3127 6 Maximum Reactive Power a (VAR1)
with Time
Float + time stamp VAR - R
3133 6 Maximum Reactive Power b (VAR1)
with Time
Float + time stamp VAR - R
3139 6 Maximum Reactive Power c (VAR1)
with Time
Float + time stamp VAR - R
3145 6 Maximum Power Factor a with Time Float + time stamp - 0 … 1 R
