Operator control
8.3 Special displays
SENTRON PAC4200
134 System Manual, 09/2009, A5E02316180B-02
Table of instantaneous values
The table below lists the instantaneous values of the fundamental.
Figure 8-15 Phasor diagram, instantaneous values
Table 8- 6 Values in the phasor diagram
V Voltage ph-n
A Current
COS Cosine of the displacement angle φ
φ Displacement angle φ
U Phase angle
