SENTRON PAC4200 - Technical data of the SENTRON PAC 4 DI;2 DO expansion module

Technical data
11.6 Technical data of the SENTRON PAC 4DI/2DO expansion module
SENTRON PAC4200
188 System Manual, 09/2009, A5E02316180B-02
11.6 Technical data of the SENTRON PAC 4DI/2DO expansion module
Mechanical data
Table 11- 8 Mechanical data of the SENTRON PAC 4DI/2DO expansion module
Values
Dimensions of housing (height x width x depth) 63 mm x 43 mm x 22 mm
Dimensions of housing with terminal block (height
x width x depth)
70.3 mm x 43 mm x 22 mm
Mounting position Vertical on the SENTRON PAC Power Monitoring
Device
Housing design VDT 3400 structure 36
Tolerances According to DIN 16901:1982-11
Weight 38 g
Connector to SENTRON PAC Power Monitoring
Device
14-pin connector
Power supply Power supplied by SENTRON PACxxxx
Cooling Passive air cooling in form of ventilation slots
Flammability class V-0
Electrical data
Table 11- 9 Electrical data of the SENTRON PAC 4DI/2DO expansion module
Values
Electrical isolation between the SENTRON PAC
and the 4DI/2DO interface
500 V
Insulating voltage Max. 500 V
Galvanic isolation of the supply voltage
1) Formerly RS 485
