Appendix
A.3 MODBUS
SENTRON PAC4200
266 System Manual, 09/2009, A5E02316180B-02
Value Assignment
228 = 23rd Harmonic Current c
229 = 25th Harmonic Current a
230 = 25th Harmonic Current b
231 = 25th Harmonic Current c
232 = 27th Harmonic Current a
233 = 27th Harmonic Current b
234 = 27th Harmonic Current c
235 = 29th Harmonic Current a
236 = 29th Harmonic Current b
237 = 29th Harmonic Current c
238 = 31st Harmonic Current a
239 = 31st Harmonic Current b
240 = 31st Harmonic Current c
241 = Process operating hours counter
See also
Configuration settings with the function codes 0x03, 0x04, and 0x10 (Page 254)
Measured variables (Page 199)
A.3.14 Communication settings with the function codes 0x03, 0x04, and 0x10
Addressing the communication settings
Table A- 24 Communication settings
Offset Number of
registers
Name Format Unit Applicable
MODBUS function
codes
Value range Access
63001 2 IP Address Unsigned long -
• 0x03
• 0x04
• 0x10
0 ... FFFFFFFFh RW
63003 2 Subnetmask Unsigned long -
• 0x03
• 0x04
• 0x10
0 ... FFFFFFFFh RW
63005 2 Gateway Unsigned long -
• 0x03
• 0x04
• 0x10
0 ... FFFFFFFFh RW
63007 2 Bootloader Version Unsigned long -
• 0x03
• 0x04
char, uchar, uchar,
uchar
R
