Appendix
A.3 MODBUS
SENTRON PAC4200
232 System Manual, 09/2009, A5E02316180B-02
Offset Number of
registers
Name Format Unit Value range Access
357 2 Sliding Window Demand Total Active
Power
Float W - R
359 2 Sliding Window Demand Total Reactive
Power (VARn)
Float VAR - R
361 2 Sliding Window Demand Total Reactive
Power (VARtot)
Float VAR - R
363 2 Sliding Window Demand Total Reactive
Power (VAR1)
Float VAR - R
365 2 Sliding Window Demand Total Power
Factor
Float - - R
367 2 Sliding Window Demand Neutral Current Float A - R
369 2 Process operating hours counter
**)
Unsigned long s 0 … 999 999 999 RW
371 2 universal counter 2
**)
Unsigned long - 0 … 999 999 999 RW
373 2 Pulse counter 0
**)
Unsigned long - 0 … 999 999 999 RW
375 2 Pulse counter 02
**)
Unsigned long - 0 … 999 999 999 RW
377 2 Pulse counter 03
**)
Unsigned long - 0 … 999 999 999 RW
379 2 Pulse counter 04
**)
Unsigned long - 0 … 999 999 999 RW
381 2 Pulse counter 05
**)
Unsigned long - 0 … 999 999 999 RW
383 2 Pulse counter 06
**)
Unsigned long - 0 … 999 999 999 RW
385 2 Pulse counter 07
**)
Unsigned long - 0 … 999 999 999 RW
387 2 Pulse counter 08
**)
Unsigned long - 0 … 999 999 999 RW
389 2 Pulse counter 09
**)
Unsigned long - 0 … 999 999 999 RW
391 2 Pulse counter 10
**)
Unsigned long - 0 … 999 999 999 RW
The following tables contain further details of all measured variables indicated by *).
You can additionally use the Modbus function code 0x10 on all measured variables indicated by **).
Table A- 2 Meaning of the abbreviations in the "Access" column
Abbreviation Meaning
R Read access
W Write access
RW Read and write access
See also
Structure - Digital inputs status and digital outputs status with the function codes 0x01 and
0x02 (Page
233)
Structure - Limit values with the function codes 0x01 and 0x02 (Page 234)
Structure - PMD diagnostics and status with the function codes 0x03 and 0x04 (Page 234)
