Appendix
A.3 MODBUS
SENTRON PAC4200
260 System Manual, 09/2009, A5E02316180B-02
Offset Number of
registers
Name Format Unit Value range Access
Byte 2 Port
Byte 2 0 ... 11
Byte 3 Bit
50253 2 Universal Counter 2 DI count
signal
Unsigned long -
Byte 3 0 ... 7
RW
61167 7 Digital Input Parameters Unsigned long - uchar RW
61175 7 Digital Output Parameters stOutputPara - uchar RW
62101 8 Event Recording Parameters stEventPara - uchar RW
62301 27 Logically Combined Limit
Parameters
stCombLimitPa
ra
- - RW
1)
Subperiods 0 and 1: Fixed block method; subperiods 0 to 5: Rolling block method
2)
More information is given in the chapter under the also-see link.
See also
Value range for limit source (Page 260)
A.3.13 Value range for limit source
Assignment of the value range for the Limit x Source parameter
Table A- 23 Assignment of the values 0 to 241
Value Assignment
0 = Voltage a-n
1 = Voltage b-n
2 = Voltage c-n
3 = Voltage a-b
4 = Voltage b-c
5 = Voltage c-a
6 = Current a
7 = Current b
8 = Current c
9 = Apparent Power a
10 = Apparent Power b
11 = Apparent Power c
12 = Active Power a
13 = Active Power b
14 = Active Power c
15 = Reactive Power a (VARn)
16 = Reactive Power b (VARn)
17 = Reactive Power c (VARn)
