Appendix
A.3 MODBUS
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
261
Value Assignment
18 = Sliding Window Demand Voltage a-n
19 = Sliding Window Demand Voltage b-n
20 = Sliding Window Demand Voltage c-n
21 = Sliding Window Demand Voltage a-b
22 = Sliding Window Demand Voltage b-c
23 = Sliding Window Demand Voltage c-a
24 = Sliding Window Demand Current a
25 = Sliding Window Demand Current b
26 = Sliding Window Demand Current c
27 = Sliding Window Demand Apparent Power a
28 = Sliding Window Demand Apparent Power b
29 = Sliding Window Demand Apparent Power c
30 = Sliding Window Demand Active Power a
31 = Sliding Window Demand Active Power b
32 = Sliding Window Demand Active Power c
33 = Sliding Window Demand Reactive Power a (VARn)
34 = Sliding Window Demand Reactive Power b (VARn)
35 = Sliding Window Demand Reactive Power c (VARn)
36 = Sliding Window Demand Total Reactive Power a (VARtot)
37 = Sliding Window Demand Total Reactive Power b (VARtot)
38 = Sliding Window Demand Total Reactive Power c (Qtot)
39 = Sliding Window Demand Reactive Power a (VAR1)
40 = Sliding Window Demand Reactive Power b (VAR1)
41 = Sliding Window Demand Reactive Power c (VAR1)
42 = Sliding Window Demand Power Factor a
43 = Sliding Window Demand Power Factor b
44 = Sliding Window Demand Power Factor c
45 = Power Factor a
46 = Power Factor b
47 = Power Factor c
48 = THD Voltage a
49 = THD Voltage b
50 = THD Voltage c
51 = THD Current a
52 = THD Current b
53 = THD Current c
54 = THD Voltage a-b
55 = THD Voltage b-c
56 = THD Voltage c-a
57 = Reactive power a (VAR1)
58 = Reactive power b (Q1)
59 = Reactive power c (Q1)
