SENTRON PAC4200 - Labeling on the SENTRON PAC 4 DI;2 DO Expansion Module

Technical data
11.9 Labeling on the SENTRON PAC 4DI/2DO expansion module
SENTRON PAC4200
192 System Manual, 09/2009, A5E02316180B-02
11.9 Labeling on the SENTRON PAC 4DI/2DO expansion module
Description
The graphic below shows the positioning of the label on the housing of the
SENTRON PAC 4DI/2DO expansion module.
s
PAC 4 DI/2DO
7KM9200-0AB00-0AA0
QAE WW JJ
Figure 11-3 SENTRON PAC 4DI/2DO expansion module with type plate
