SENTRON PAC4200 - Table A- 21 Harmonics of the Current

Appendix
A.3 MODBUS
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
251
Offset Number of
registers
Name Format Unit Value range Access
13155 6 Maximum 19th Harmonic Voltage c-n
with Time
Float + time stamp % - R
13161 6 Maximum 21st Harmonic Voltage a-n
with Time
Float + time stamp % - R
13167 6 Maximum 21st Harmonic Voltage b-n
with Time
Float + time stamp % - R
13173 6 Maximum 21st Harmonic Voltage c-n
with Time
Float + time stamp % - R
13179 6 Maximum 23rd Harmonic Voltage a-n
with Time
Float + time stamp % - R
13185 6 Maximum 23rd Harmonic Voltage b-n
with Time
Float + time stamp % - R
13191 6 Maximum 23rd Harmonic Voltage c-n
with Time
Float + time stamp % - R
13197 6 Maximum 25th Harmonic Voltage a-n
with Time
Float + time stamp % - R
13203 6 Maximum 25th Harmonic Voltage b-n
with Time
Float + time stamp % - R
13209 6 Maximum 25th Harmonic Voltage c-n
with Time
Float + time stamp % - R
13215 6 Maximum 27th Harmonic Voltage a-n
with Time
Float + time stamp % - R
13221 6 Maximum 27th Harmonic Voltage b-n
with Time
Float + time stamp % - R
13227 6 Maximum 27th Harmonic Voltage c-n
with Time
Float + time stamp % - R
13233 6 Maximum 29th Harmonic Voltage a-n
with Time
Float + time stamp % - R
13239 6 Maximum 29th Harmonic Voltage b-n
with Time
Float + time stamp % - R
13245 6 Maximum 29th Harmonic Voltage c-n
with Time
Float + time stamp % - R
13251 6 Maximum 31st Harmonic Voltage a-n
with Time
Float + time stamp % - R
13257 6 Maximum 31st Harmonic Voltage b-n
with Time
Float + time stamp % - R
13263 6 Maximum 31st Harmonic Voltage c-n
with Time
Float + time stamp % - R
Table A- 21 Harmonics of the current
Offset Number of
registers
Name Format Unit Value range Access
19001 6 Maximum Fundamental Current a with
Time
Float + time stamp A - R
19007 6 Maximum Fundamental Current b with
Time
Float + time stamp A - R
