Connecting
6.3 Connecting the cables to the terminals
SENTRON PAC4200
86 System Manual, 09/2009, A5E02316180B-02
6.3 Connecting the cables to the terminals
Connecting cables to the screw terminal
Tool: PZ2 cal. screwdriver ISO 6789
Figure 6-7 Connecting cables to the screw terminal
Connecting the cables to the ring lug terminals:
Note
The SENTRON PAC4200 with ring lug terminal is intended for:
• use in NAFTA / USA
• Regions in which open terminals are permitted.
WARNING
Improper connection may result in death, serious injury, or property damage.
Only connect ring lugs to ring lug terminals. Ensure proper attachment of ring lugs to
cables.
Tool: PZ2 cal. screwdriver ISO 6789
