Appendix
A.3 MODBUS
SENTRON PAC4200
262 System Manual, 09/2009, A5E02316180B-02
Value Assignment
60 = Total Reactive Power a (VARtot)
61 = Total Reactive Power b (VARtot)
62 = Total Reactive Power c (VARtot)
63 = Cos φ a
64 = Cos φ b
65 = Cos φ c
66 = Distortion Current a
67 = Distortion Current b
68 = Distortion Current c
69 = Phase Angle a-a
70 = Phase Angle a-b
71 = Phase Angle a-c
72 = Displacement Angle a
73 = Displacement Angle b
74 = Displacement Angle c
75 = Line Frequency
76 = 3-Phase Average Voltage ph-n
77 = 3-Phase Average Voltage ph-ph
78 = 3-Phase Average Current
79 = Total Apparent Power
80 = Total active power
81 = Total Reactive Power (VARn)
82 = Total Reactive Power (VAR1)
83 = Total Reactive Power (VARtot)
84 = Sliding Window Demand Total Apparent Power
85 = Sliding Window Demand Total Active Power
86 = Sliding Window Demand Total Power Factor
87 = Sliding Window Demand Total Reactive Power (VARn)
88 = Sliding Window Demand Total Reactive Power (VAR1)
89 = Sliding Window Demand Total Reactive Power (VARtot)
90 = Total Power Factor
91 = Amplitude Unbalance Voltage
92 = Amplitude Unbalance Current
93 = Unbalance Voltage
94 = Unbalance Current
95 = Neutral Current
96 = Sliding Window Demand Neutral Current
97 = Fundamental Voltage a-n
98 = Fundamental Voltage b-n
99 = Fundamental Voltage c-n
100 = 3rd Harmonic Voltage a-n
101 = 3rd Harmonic Voltage b-n
