SENTRON PAC4200 - Page 214

Appendix
A.1 Measured variables
SENTRON PAC4200
214 System Manual, 09/2009, A5E02316180B-02
Name Abbrev.
DE + IEC
Abbrev.
EN + UL
Unit Dis-
play
LIM
SOURCE
19th harmonic voltage c-a h
19 L3-L1
h
19 c-a
% 16.2 H19 V ca
21st harmonic voltage c-a h
21 L3-L1
h
21 c-a
% 16.2 H21 V ca
23rd harmonic voltage c-a h
23 L3-L1
h
23 c-a
% 16.2 H23 V ca
25th harmonic voltage c-a h
25L3-L1
h
25 c-a
% 16.2 H25 V ca
27th harmonic voltage c-a h
27 L3-L1
h
27 c-a
% 16.2 H27 V ca
29th harmonic voltage c-a h
29 L3-L1
h
29 c-a
% 16.2 H29 V ca
31st harmonic voltage c-a h
31 L3-L1
h
31 c-a
% 16.2 H31 V ca
Harmonic content of the 3rd, 5th, 7th, … 31st harmonics for the voltage between c and a referred to
the fundamental
Maximum Harmonics Voltage c-a
Maximum 3rd harmonic voltage c-a h
3 L3-L1 max
h
3 c-a max
% 16.1
Maximum 5th harmonic voltage c-a h
5 L3-L1 max
h
5 c-a max
% 16.1
Maximum 7th harmonic voltage c-a h
7 L3-L1 max
h
7 c-a max
% 16.1
Maximum 9th harmonic voltage c-a h
9 L3-L1 max
h
9 c-a max
% 16.1
Maximum 11th harmonic voltage c-a h
11 L3-L1 max
h
11 c-a max
% 16.1
Maximum 13th harmonic voltage c-a h
13 L3-L1 max
h
13 c-a max
% 16.1
Maximum 15th harmonic voltage c-a h
15 L3-L1 max
h
15 c-a max
% 16.1
Maximum 17th harmonic voltage c-a h
17 L3-L1 max
h
17 c-a max
% 16.1
Maximum 19th harmonic voltage c-a h
19 L3-L1 max
h
19 c-a max
% 16.2
Maximum 21st harmonic voltage c-a h
21 L3-L1 max
h
21 c-a max
% 16.2
Maximum 23rd harmonic voltage c-a h
23 L3-L1 max
h
23 c-a max
% 16.2
Maximum 25th harmonic voltage c-a h
25 L3-L1 max
h
25 c-a max
% 16.2
Maximum 27th harmonic voltage c-a h
27 L3-L1 max
h
27 c-a max
% 16.2
Maximum 29th harmonic voltage c-a h
29 L3-L1 max
h
29 c-a max
% 16.2
Maximum 31st harmonic voltage c-a h
31 L3-L1 max
h
31 c-a max
% 16.2
Maximum value of the harmonic content of the 3rd, 5th, 7th, … 31st harmonics for the voltage
between c and a referred to the fundamental
Harmonics Current a
Fundamental current a I
1 L1
I
1 a
A 17 H1 I a
Value of the current of the fundamental in a
3rd harmonic current a I
3 L1
I
3 a
A 17 H3 I a
5th harmonic current a I
5 L1
I
5 a
A 17 H5 I a
7th harmonic current a I
7 L1
I
7 a
A 17 H7 I a
9th harmonic current a I
9 L1
I
9 a
A 17 H9 I a
11th harmonic current a I
11 L1
I
11 a
A 17 H11 I a
13th harmonic current a I
13 L1
I
13 a
A 17 H13 I a
15th harmonic current a I
15 L1
I
15 a
A 17 H15 I a
17th harmonic current a I
17 L1
I
17 a
A 17.2 H17 I a
19th harmonic current a I
19 L1
I
19 a
A 17.2 H19 I a
21st harmonic current a I
21 L1
I
21 a
A 17.2 H21 I a
23rd harmonic current a I
23 L1
I
23 a
A 17.2 H23 I a
25th harmonic current a I
25L1
I
25 a
A 17.2 H25 I a
