Appendix
A.1 Measured variables
SENTRON PAC4200
222 System Manual, 09/2009, A5E02316180B-02
Name Abbrev.
DE + IEC
Abbrev.
EN + UL
Unit Dis-
play
LIM
SOURCE
Minimum sliding window demand reactive power b
(VARn)
Q
n L2 sw-dmd min
VAR
n b sw-dmd min
VAR 6.5
Minimum value of the sliding window demand of the reactive power of the harmonics in phase
conductor b, measured according to VARn
Sliding window demand reactive power c (VARn) Q
n L2 sw-dmd
VAR
n c sw-dmd
VAR 6.3 VARn DMD c
Sliding window demand of the reactive power of the harmonics in phase conductor c, measured
according to VARn
Maximum sliding window demand reactive power c
(VARn)
Q
n L3 sw-dmd max
VAR
n c sw-dmd max
VAR 6.4
Maximum value of the sliding window demand of the reactive power of the harmonics in phase
conductor c, measured according to VARn
Minimum sliding window demand reactive power c
(VARn)
VAR
n L3 sw-dmd
min
VAR
n c sw-dmd min
VAR 6.5
Minimum value of the sliding window demand of the reactive power of the harmonics in phase
conductor c, measured according to VARn
Sliding Window Demand Reactive Power a (VAR1) VAR
1 a sw-dmd
VAR
1 a sw-dmd
VAR 6.3 VAR1 DMD a
Sliding window demand of the reactive power of the fundamental in phase conductor a referred to the
load counting system, measured according to VAR1
Maximum sliding window demand reactive power a
(VAR1)
Q
1 L1 sw-dmd max
VAR
1 a sw-dmd max
VAR 6.4
Maximum value of the sliding window demand of the reactive power of the fundamental in phase
conductor a, measured according to VAR1
Minimum sliding window demand reactive power a
(VAR1)
VAR
1 a sw-dmd
min
VAR
1 a sw-dmd min
VAR 6.5
Minimum value of the sliding window demand of the reactive power of the fundamental in phase
conductor a, measured according to VAR1
Sliding window demand reactive power b (VAR1) VAR
1 b sw-dmd
VAR
1 b sw-dmd
VAR 6.3 VAR1 DMD b
Sliding window demand of the reactive power of the fundamental in phase conductor b referred to the
load counting system, measured according to VAR1
Maximum sliding window demand reactive power b
(VAR1)
VAR
1 b sw-dmd
max
VAR
1 b sw-dmd max
VAR 6.4
Maximum value of the sliding window demand of the reactive power of the fundamental in phase
conductor b, measured according to VAR1
Minimum sliding window demand reactive power b
(VAR1)
VAR
1 b sw-dmd
min
VAR
1 b sw-dmd min
VAR 6.5
Minimum value of the sliding window demand of the reactive power of the fundamental in phase
conductor b, measured according to VAR1
Sliding window demand reactive power c (VAR1) Q
1 L3 sw-dmd
VAR
1 c sw-dmd
VAR 6.3 VAR1 DMD c
Sliding window demand of the reactive power of the fundamental in phase conductor c referred to the
load counting system, measured according to VAR1
Maximum sliding window demand reactive power c
(VAR1)
VAR
1 c sw-dmd
max
VAR
1 c sw-dmd max
VAR 6.4
Maximum value of the sliding window demand of the reactive power of the fundamental in phase
conductor c, measured according to VAR1
