Appendix
A.3 MODBUS
SENTRON PAC4200
System Manual, 09/2009, A5E02316180B-02
255
Offset Number of
registers
Name Format Unit Value range Access
1 = Edge
0 = Import kWh
1 = Export kWh
2 = Import kVARh
3 = Export kVARh
50029 2 DI 0.0 Use of Counter
Information
Unsigned long -
4 = Description
RW
50031 2 DI 0.0 Significance of of
Counter Information
Unsigned long - 1 ... 999 RW
50033 2 DO 0.0 Vector Group
Assignment
Unsigned long - 0 ... 99 RW
0 = OFF
1 = Device ON
2 = Remote output
3 = Rotation
4 = Lim. violation
5 = Energy pulse
50035 2 DO 0.0 Type of Use Unsigned long -
6 = Sync
RW
0 = Limit logic
1 = Limit 0
2 = Limit 1
3 = Limit 2
4 = Limit 3
5 = Limit 4
50037 2 DO 0.0 Limit Assignment Unsigned long -
6 = Limit 5
RW
0 = Pulse 50039 2 DO 0.0 Pulse / Edge Evaluation Unsigned long -
1 = Edge
RW
0 = Import kWh
1 = Export kWh
2 = Import kVARh
50041 2 DO 0.0 Source Count Signal Unsigned long -
3 = Export kVARh
RW
50043 2 DO 0.0 Significance of of
Counter Information
Unsigned long - 1 ... 999 RW
50045 2 DO 0.0 Pulse Length Unsigned long - 30 ... 500 RW
0 = German
1 = English
2 = Portuguese
3 = Turkish
4 = Spanish
5 = Italian
6 = Russian
7 = French
50047 2 Dialog Language Unsigned long -
8 = Chinese
RW
