SERES 5 - Page 201

Vehicle Specifications 丨 201
1
2
3
4
5
6
7
8
9
10
11
12
13
Range extender (Engine) Parameters
Items
Parameter
Range extender model
H15RT
Maximum Net Power/Speed (kW/rpm)
85/5000
Rated Power/Speed (kW/rpm)
85/5000
Maximum Torque/Speed (N·m/rpm)
190/3500
Type
Inline four-cylinder, multi-point fuel injection, intake VVT,
low-pressure EGR
Bore × Stroke (mm)
73.5×88.32
Displacement (mL)
1499
Emission Standard
R83.07
Drive Motor Parameters
Items
SE165
SE200
Motor Type
AC Asynchronous
Permanent Magnet Synchronous
Rated Voltage (V)
350
350
Continuous Power of the Motor (kW)
42
73
Peak Power of the Motor (kW)
162
196
Continuous Torque of the Motor (N·m)
63
142
Peak Torque of the Motor (N·m)
310
354
Rated Speed of the Motor (rpm)
6250
4966
Peak Speed of the Motor (rpm)
17600
17600
