SERES 5 - Page 202

202 丨 Vehicle Specifications
Tire and Hub Parameters
Tire size/type
Recommended tire pressure (cold tire)
Dynamic balance
requirement (g)
Rim model
Unloaded
kPa/bar
Full load
kPa/bar
Front
Rear
Front
Rear
255/45R20
280/2.8
300/3.0
≤5
8.5J×20
Please refer to the actual vehicle for tire specifications.
Four-wheel alignment parameters (unloaded)
Wheel alignment type
Parameter
Front wheel camber
-0°30′±0°20′
Rear wheel camber
-1°25′±0°20′
Main pivot inclination angle
+3°26′±0°30′
Main pivot rear tilt angle
+3°48′±0°30′
Front wheel front camber
+0°05′±0°05′
Rear wheel front camber
+0°10′±0°05′
Power Battery Parameters
Items
Parameter
Power battery type
Lithium-ion battery
Rated capacity (Ah)
114
Nominal voltage (V)
351.36
Charging time (h)
Fast charging
1
: 0.5 (30%~80%); slow charging
2
: 3.3 (25%~90%)
1: Ambient temperature is room temperature, fast charging station maximum charging power ≥80kW.
2: Ambient temperature is room temperature, slow charging station maximum charging power ≥11kW.
