Manual – IPOSplus®
53
6
Encoder evaluation
Position Detection and Positioning
6 Position Detection and Positioning
6.1 Encoder evaluation
MOVIDRIVE
®
offers various options for positioning:
• external encoders
• Motor encoder (incremental encoder/resolver)
• Hiperface
®
encoder (absolute encoder)
• SSI absolute encoder
The values are provided in system variables for processing.
The connections for the motor encoder (X15) and external encoder (X14) are in the con-
trol electronics MxV..., MxS... und MCH... . The control electronics MxF does not have
these connections. The connection for the SSI absolute encoder is on the DIP11 option
card (X62).
All connected encoders are always evaluated regardless of the operating mode (P700).
Operating modes with positioning (VFC-n-CTRL & IPOS, CFC & IPOS, SERVO & IPOS)
always require a motor encoder at X15.
Encoder type
Absolute encoder on DIP11
P941: Absolute encoder (DIP)
Hiperface
®
encoder / incre-
mental encoder simulation /
incremental encoder
P941: External encoder (X14)
Incremental encoder /
Resolver / Hiperface
®
encoder
P941: Motor encoder (X15)
Connection X62/DIP11 X14/basic unit X15/basic unit
Actual value on variable H509 / ACTPOS. ABS /
ActPos_Abs
H510 / ACTPOS. EXT /
ActPos_Ext
H511 / ACTPOS. MOT /
ActPos_Mot
Resolution Absolute position after conver-
sion with:
Encoder scaling (P955),
Zero offset (P954),
Position offset (P953),
Counting direction (P951).
Actual encoder resolution (with
4-fold evaluation) after conver-
sion with:
Encoder scaling ext. encoder
(P944)
Always 4096 inc./motor revolu-
tion, regardless of the actual
encoder resolution
Touch
probe
Edge at DI02 H503 / TP. POS1ABS /
TpPos1_Abs
H506 / TP. POS1EXT /
TpPos1_Ext
H507 / TP. POS1MOT /
TpPos1_Mot
Edge at DI03 H502 / TP. POS2ABS /
TpPos2_Abs
H504 / TP. POS2EXT /
TpPos2_Ext
H505 / TP. POS2MOT /
TpPos2_Mot
Max. delay time 1 ms < 100 µs < 100 µs
