Sharp MX-2300G Service Manual

MX3500N SIMULATION 7 – 14
<Inner finisher (MX-FNX1)>
<4K finisher>
<4K saddle finisher>
[Screen (Saddle finisher (MX-FNX2) installed)]
4
4-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and detectors in the desk/large capac-
ity tray and the related circuit.
Section
Desk/Large capacity tray (LCC)
Item
Operation
Operation/Procedure
The active sensors and detectors are highlighted.
The active sensors and detectors are highlighted.
<Desk sensor>
<A4 LCC sensor>
<A3 LCC sensor>
J PUNCH HOLE Punch hole position
adjustment
0 to 100 50
Item Display Item Set range
Default
value
A FRONT ADJUST Alignment position
adjustment (front)
2 to 18 10
B REAR ADJUST Alignment position
adjustment (rear)
2 to 18 10
C STAPLE REAR Staple binding position
adjustment (one
position at the rear)
68 to 132 100
D STAPLE FRONT Staple binding position
adjustment (one
position in front)
68 to 132 100
E STAPLE BOTH Staple binding position
adjustment (two
positions at the
center)
68 to 132 100
F STAPLE PITCH Staple binding position
adjustment (two
positions in pitch)
68 to 132 100
G PUNCH
CENTER
Punch center
adjustment
37 to 63 50
H PUNCH HOLE Punch hole position
adjustment
42 to 58 50
Item Display Item Set range
Default
value
A FRONT ADJUST Alignment position
adjustment (front)
0 to 20 10
B STAPLE REAR Staple binding position
adjustment (one
position at the rear)
94 to 106 100
C STAPLE FRONT Staple binding position
adjustment (one
position in front)
94 to 106 100
D PUNCH
CENTER
Punch center
adjustment
40 to 60 50
E PUNCH HOLE Punch hole position
adjustment
46 to 52 50
Item Display Item Set range
Default
value
A SADDLE
POSITOIN
Saddle binding
position adjustment
197 to 203 200
BFOLDING
POSITION
Saddle folding
position adjustment
192 to 208 200
C FRONT ADJUST Alignment position
adjustment (front)
0 to 20 10
D STAPLE REAR Staple binding position
adjustment (one
position at the rear)
94 to 106 100
E STAPLE FRONT Staple binding position
adjustment (one
position in front)
94 to 106 100
F PUNCH
CENTER
Punch center
adjustment
40 to 60 50
G PUNCH HOLE Punch hole position
adjustment
46 to 52 50
Item Display Item Set range
Default
value
DCSI1 Desk 1 installation detection
DPFD1 Desk 1 transport detection
DLUD1 Desk 1 upper limit detection
DPED1 Desk 1 paper empty detection
DCSPD1 Desk 1 remaining paper quantity detection
DCSS11 Desk 1 rear edge detection 1
DCSS12 Desk 1 rear edge detection 2
DCSS13 Desk 1 rear edge detection 3
DCSS14 Desk 1 rear edge detection 4
DCSI2 Desk 2 instillation detection
DPFD2 Desk 2 transport detection
DLUD2 Desk 2 upper limit detection
DPED2 Desk 2 paper empty detection
DCSPD2 Desk 2 remaining paper quantity detection
DCSS21 Desk 2 rear edge detection 1
DCSS22 Desk 2 rear edge detection 2
DCSS23 Desk 2 rear edge detection 3
DCSS24 Desk 2 rear edge detection 4
DSW_DSK Desk transport cover open/close detection
LPFD LCC transport sensor
LUD LCC tray upper limit sensor
LDD LCC tray lower limit sensor
LPED LCC tray paper empty sensor
LCD LCC tray insertion detection
LDSW LCC upper open/close detection SW
LRE LCC lift motor encoder sensor
L24VM LCC 24V power monitor
LLSW LCC upper limit SW
LTOD LCC main unit connection detection
LPFD LCC transport sensor
LUD LCC tray upper limit sensor
LDD LCC tray lower limit sensor
LPED LCC tray paper empty sensor
LCD LCC tray insertion detection
LDSW LCC upper open/close detection SW
LRE LCC lift motor encoder sensor
0
A
:
A㧦200
B㧦200
C㧦 10
D㧦 10
㧧
SADDLE POSITION
㧧 FOLDING POSITION
㧧 FRONT ADJUSUT
㧧 REAR ADJUSUT
SIMULATION  NO.03-10
FINISHER ADJUSTMENT
200
㨇 0 㨪 400 㨉
OK
TEST
CLOSE
