Sharp MX-2300G Service Manual

MX3500N SIMULATION 7 – 29
24-7
Purpose
Data clear
Function (Purpose)
Used to clear the OPC drum counter. (After
replacement of the OPC drum, clear the
counter.)
Section
—
Item
Counter (OPC drum)
Operation/Procedure
1) Select the item to be cleared with the buttons on the touch
panel.
2) Press [EXECUTE] button.
3) Press [YES] button.
The target counter is cleared.
* The "accumulated number of drum rotation" counter of SIM22-01
is not displayed on the execution screen of this simulation, but it
is cleared in connection with execution of this simulation.
24-9
Purpose
Data clear
Function (Purpose)
Used clear the printer mode print counter
and the self print mode print counter.
Section
—
Item
Counter
Operation/Procedure
1) Select the item to be cleared with the buttons on the touch
panel.
2) Press [EXECUTE] button.
3) Press [YES] button.
The target counter is cleared.
24-10
Purpose
Data clear
Function (Purpose)
Used to clear the FAX counter. (Only when
FAX is installed)
Section
—
Item
Counter
Operation/Procedure
1) Select the item to be cleared with the buttons on the touch
panel.
2) Press [EXECUTE] button.
3) Press [YES] button.
The target counter is cleared.
24-15
Purpose
Data clear
Function (Purpose)
Used to clear the counters related to the
image send.
Section
—
Item
Counter
Operation/Procedure
1) Select the item to be cleared with the buttons on the touch
panel.
2) Press [EXECUTE] button.
3) Press [YES] button.
The target counter is cleared.
K Drum cartridge print counter (K)
Drum cartridge accumulated traveling distance (cm) (K)
C Drum cartridge print counter (C)
Drum cartridge accumulated traveling distance (cm) (C)
M Drum cartridge print counter (M)
Drum cartridge accumulated traveling distance (cm) (M)
Y Drum cartridge print counter (Y)
Drum cartridge accumulated traveling distance (cm) (Y)
PRINT BW Printer (B/W) counter
PRINT COL Printer (COLOR) counter
OTHER BW Other (BW) counter
OTHER COL Other (COLOR) counter
ARE YOU SURE?
YES NO
EXECUTE
0
SIMULATION  NO.24  07
TEST
DRUM CTRG COUNTER CLEAR
1/1
 K
 C
 M  Y
CLOSE
ARE YOU SURE?
YES NO
EXECUTE
0
SIMULATION  NO.24  09
TEST
PRINT/OTHER COUNTER CLEAR
1/1
PRINT BW
PRINT COL
OTHER BW
OTHER COL
CLOSE
FAX OUTPUT Print quantity counter (for line 1)
FAX OUTPUT_L2 Print quantity counter (for line 2)
FAX SEND Send counter
FAX RECEIVED FAX receive counter
SEND IMAGES FAX send quantity counter (for line 1)
SEND IMAGES_L2 FAX send quantity counter (for line 2)
SEND TIME FAX send time
RECEIVED TIME FAX receive time
ACR SEND Number of carrier prefix attached communications
NET SCN ORG_B/W Network scanner document read quantity
counter (B/W) (B/W scan job)
NET SCN ORG_CL Network scanner document read quantity
counter (COLOR) (COLOR scan job)
NET SCN ORG_2CL Network scanner document read quantity
counter (2-color) (2-color scan job)
NET SCN ORG_SGL Network scanner document read quantity
counter (Single) (Single scan job)
INTERNET FAX
OUTPUT
Internet FAX output quantity
INTERNET FAX SEND
OUTPUT
Internet FAX send quantity
INTERNET FAX
RECEIVE
Number of internet FAX receive
INTERNET FAX SEND Number of internet FAX send
MAIL COUNTER Number of E-Mail send
FTP COUNTER Number of FTP send
SMB SEND Numeric SMB send
USB CNT Number of USB save
TRIAL MODE_B&C Trial mode counter (B/W & COLOR scan job)
SCAN TO HDD_B/W Scan to HDD record quantity (B/W)
A
RE YOU SURE?
YES NO
EXECUTE
0
SIMULATIO N  NO.24  10
TEST
FAX COUNTER DATA CLEAR
1/1
FA
X
 OUTPUT
FA X O U T PU T _ L 2
CLOSE
FAX SEND FAX RECEIVED
SEND IMAGES
SEND IMAGES_L2
SE N D TI ME R EC E I VE D TI ME
ACR  SEND
