MX3500N SIMULATION 7 – 42
27-9
Purpose
Setting
Function (Purpose)
Used to set the threshold value for deter-
mining whether the paper feed time
between sensors is recorded or not and the
threshold value for determining whether the
gain adjustment retry number is recorded
or not.
Section
—
Item
Specifications
Operation/Procedure
1) When the machine enters the simulation, the following screen
is displayed.
2) Select an item to be set with [↑] and [↓] buttons.
The highlighted section of the set value is changed and the
value is displayed in the setting area.
* When there is an item over [↑], the display becomes active
and shifts to another item.
When there is no item over [↑], the display grays out and the
operation is disabled.
When there is an item under [↓], the display becomes active
and shifts to another item.
When there is no item under [↓], the display grays out and
the operation is disabled.
3) Enter the set value with 10-key.
* Press [C] key to clear the entered value.
4) When [OK] button is pressed, the current set value is saved to
EEPROM and RAM.
After completion of setting, [OK] button returns to the normal
display.
* When [COLOR], or [BLACK] key is pressed, the current set
value is saved to EEPROM and RAM.
<Setting range and default value of each value>
* Item A: 0% is the standard passing time between sheets. 100%
is the time for judgment as a JAM between sheets.
27-10
Purpose
Data clear
Function (Purpose)
Used to clear the trouble prediction history
information.
Section
Communication (RIC/MODEM)
Item
Specifications
Operation/Procedure
1) Press [EXECUTE] button.
[EXECUTE] button is highlighted, and [YES] and [NO] buttons
become active display.
2) Press [YES] button.
The history information of the trouble prediction information is
cleared. [YES] button is highlighted.
* When [NO] button or [EXECUTE] button is pressed, [EXE-
CUTE] button returns to the normal display and [YES] and
[NO] buttons gray out.
* After completion of the trouble prediction information history
clear, [EXECUTE] button returns to the normal display and
[YES] and [NO] buttons gray out.
<Clear target history item>
27-11
Purpose
Adjustment/Setup/Operation data output/
Check (Display/Print)
Function (Purpose)
Used to display the serial communication
retry number and the scanner gain adjust-
ment retry number history.
Section
Communication (RIC/MODEM)
Item
Specification
Operation/Procedure
1) When the machine enters Simulation 27-11, the following
screen is displayed.
* Select the display page of process data with [↓] and [↑] but-
tons.
* When there is an item over [↑], the display becomes active
and shifts to the previous page.
When there is no item over [↑], the display grays out and the
operation is disabled.
When there is an item under [↓], the display becomes active
and shifts the following page.
When there is no item under [↓], the display grays out and
the operation is disabled.
* When [CLOSE] button is pressed, the display shifts to the copy
basic screen of the simulation.
* Press [COLOR]/[BLACK] key to execute copying.
Item Display Content
Setting
range
Default
value
A FEED TIME1 Threshold value of paper
feed time between sensors
(Main unit)
0 to 100 50 (%)
B FEED TIME2 Threshold value of paper
feed time between sensors
(SPF)
0 to 100 50 (%)
CGAIN
ADJUSTMENT
RETRY
Threshold value of gain
adjustment retry number
1 to 100 50
(TIMES)
D JAM ALERT Threshold value of
continuous JAM alert
judgment
1 to 100 10
(TIMES)
0
