Sharp MX-2300G Service Manual

MX3500N MAINTENANCE 9 – 12
H. Paper feed section
: Check (Clean, replace, or adjust according to necessity.) {: Clean : Replace : Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical
parts
When
calling
150
K
300
K
450
K
600
K
750
K
900
K
1050
K
1200
K
1350
K
1500
K
1650
K
1800
K
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Paper pickup
roller
Mechanical
parts
{{{{{{ { {{{{{(P/G No.: [10]-40, [15]-33)
2 Paper feed
roller
{{{{{{ { {{{{{(P/G No.: [10]-41, [15]-29)
3 Separation
roller
{{{{{{ { {{{{{(P/G No.: [9]-4, [14]-37)
4 Torque limiter
1
4
4
1
4
2
3
2
3
1
2
3
