Sharp MX-2300G Service Manual

MX3500N MAINTENANCE 9 – 13
I. Transport section/Paper exit reverse section
: Check (Clean, replace, or adjust according to necessity.) {: Clean : Replace : Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical
parts
When
calling
150
K
300
K
450
K
600
K
750
K
900
K
1050
K
1200
K
1350
K
1500
K
1650
K
1800
K
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the
replacement parts
are described.)
1 PS follower roller Mechanical
parts
{{{{{{ { {{{{{
2 Transport rollers {{{{{{ { {{{{{
3 Discharge brush
4 Paper exit filter
5 Gears When checking, apply
to the necessary
positions (specified
positions).
1
2
2
2
3
3
4
4
2
3
