Sharp MX-2300G Service Manual

MX3500N MAINTENANCE 9 – 14
J. Drive section
: Check (Clean, replace, or adjust according to necessity.) {: Clean : Replace : Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical
parts
When
calling
150
K
300
K
450
K
600
K
750
K
900
K
1050
K
1200
K
1350
K
1500
K
1650
K
1800
K
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Gears (Grease) Mechanical
parts
When checking, apply
to the necessary
positions (specified
positions).
2 Shaft earth
sections
(Conduction
grease)
When checking, apply
to the necessary
positions (specified
positions).
3Belts
2
1
3
1
(FLOIL G313S)
(HANARL FL955R)
