41
10. After writing to the Flash ROM is complete, the READY and FAILURE LED indicators
flash 20 times simultaneously, the CPU is reset, and the instrument is rebooted.
11. If the instrument reboots normally after the reset is applied, a message indicating that
the update is complete is displayed, as shown in Fig. 4.
12. Click the Close button to close the FLASH ROM Update window.
Fig. 4 Status Display when Update is Complete
I read better thoroughly GCMS2010.BIN.
I read BIN FILE. SIZE:168128---CHKSUM:DFB76B
It is while is forwarded BIN FILE to the device.
Please wait for a while until the updating of ROM ends.
The updating of FLASH ROM completed.
