Operating Instructions Chapter 5
C 4000 Standard/Advanced
8 009 861/OE59/19-11-04 © SICK AG • Industrial Safety Systems • Germany • All rights reserved
45
Installation and mounting
 When mounting the side bracket make sure that the bolts marked  and  remain
accessible, allowing you later to adjust and lock the light curtain in position.
 If you wish to use the additional front screen (see “Additional front screen (weld spark
guard)” on page 88), make sure that the curved side of the device remains accessible
after mounting.
Fig. 27: Mounting the C 4000
with side bracket
Notes
Sliding nut
Sliding nut


