SICK DUSTHUNTER T User Manual

Specifications
DUSTHUNTER T · Operating Instructions · 8012428 V 2.0 · © SICK MAIHAK GmbH Germany 115
7.2.3 Flange with tube
Figure 89 Flange with tube
L L = 130, 240, 500
45°
45°
M10
Ø 76
Ø 100
Ø 130
Name Part number
Flange with tube, Di = 70.2 Length 130 mm, St37 2017845
Flange with tube, Di = 70.2 Length 240 mm, St37 2017847
Flange with tube, Di = 70.2 Length 500 mm, St37 2017849
Flange with tube, Di = 70.2 Length 130 mm, 1.4571 2017846
Flange with tube, Di = 70.2 Length 240 mm, 1.4571 2017848
Flange with tube, Di = 70.2 Length 500 mm, 1.4571 2017850
