SICK FLOWSIC600-XT Service Manual

Components
FLOWSIC600-XT · Service Manual · 8019179/V0-2/2016-03 · © SICK Engineering GmbH 19
Subject to change without notice
2.2.2 Ex-de enclosure version
Fig. 6 Exploded view Ex-de
With Ex-e wiring, the Ex-d inputs and outputs run through a line duct to the Ex-e terminals in
the Ex-e terminal compartment. The type of the line duct depends on the I/O configuration.
1
2
1 Flameproof enclosure with I/O electronics
2 Ex-d terminal compartment cover
3 Ex-e terminal compartment
4 Ex-e terminal compartment cover
5 Ex-i transducer electronics with cover and backup battery
6Display unit
3
4
5
6
