54 FLOWSIC600-XT · Service Manual · 8019179/V0-2/2016-03 · © SICK Engineering GmbH
Repairs
Subject to change without notice
3.6 Parameter input
3.6.1 Configure sensor settings after transducer exchange
In order to configure settings after exchanging a transducer pair, follow these steps:
1 Open a FLOWSIC600-XT meter using the Device Manager with user level "Service" or
higher.
2 Navigate to "Service"/"Register Tree".
3 For each exchanged transducer select the appropriate branch underneath "Flow/Path
plane X/Path X-Y" and modify the following values according to the "Data Sheet Trans-
ducer Pair":
– Register "Sensor Serial X-Y Position".
– Register "Sensor Length X-Y Position".
– Register "TimeOffset X-Y".
– Register "TimeDifference".
– Register "DiffractionTime".
4 Confirm each modification by clicking "Write".
5 Repeat each above step for the each exchanged transducer.
6 Disable configuration mode, if required.
7 If required, generate a new Parameter Protocol" in "Parameter Modification".
3.6.2 SOS Check
In order to compare theoretical and measured SOS, follow these steps
For a detailed description, please refer to " FLOWgate Software Manual":
1 Open a FLOWSIC600-XT meter using the device manager with user level "Service" or
higher.
2 Navigate to “Diagnosis/SOS Calculator”.
3 Select the “Gas Composition” and click "Apply"
4 Calculate the theoretical speed of sound.
5 Open the trend chart.
– The theoretical speed of sound is visualized as a horizontal red line.
– The measured speed of sound for each path is plotted along the timeline in different
colors.
