3.5.4 Replacing the RTC battery
Prerequisites
▸ The display unit is swiveled down:
– Swivel the display unit downwards, → p. 31, §3.5.1.1.
3.5.4.1 Replace the RTC battery
1 Loosen the battery cover screw with
a Phillips screwdriven.
2 Remove the battery cover.
1 Take the RTC battery out of the
holder
2 Insert the new battery.
3 Refit the battery cover.
4 Swivel the display unit back up and screw tight, → p. 34, §3.5.1.5.
