SICK FLOWSIC600-XT Service Manual

Repairs
FLOWSIC600-XT · Service Manual · 8019179/V0-2/2016-03 · © SICK Engineering GmbH 55
Subject to change without notice
3.6.3 Configure Stacking
In order to configure Stacking of signals, please follow these steps:
1 Open a FLOWSIC600-XT meter using the device manager with user level "Service" or
higher.
2 Navigate to "Diagnostics"/"Signal View".
3 Ensure, that configuration mode is set on meter.
4 In the section "Parameters" select the appropriate stacking size 1, 2, 4, 8, or 16.
5 Click "Write to device" in the toolbar.
6 Disable configuration mode, if required.
3.6.4 Configure Zerophase
In order to configure or adjust the zerophase of a path, follow these steps:
1 Open a FLOWSIC600-XT meter using the Device Manager with user level "Service" or
higher.
2 Navigate to "Diagnostics"/"Signal View".
3 Ensure, that configuration mode is set on meter.
4 Select a path to configure.
5 Identify the current zero phase error inside the panel "Signal Values" identified by "0-
Error"
6 Inside Panel "Parameter", please modify the parameter "Phaseshift" by adding the 0-
Error to the current value of "Phase Shift"
7 Click "Write to device" in the toolbar.
8 Repeat steps 4-7 for each required path and direction.
9 Disable configuration mode, if required.
3.6.5 Configure Pfix and Tfix
In order to configure settings for Pfix or Tfix, follow these steps:
1 Open a FLOWSIC600-XT meter using the Device Manager with user level "Service" or
higher.
2 Navigate to "Parameter Modification"/"Pressure/Temperature Sensors".
3 Ensure, that configuration mode is set on meter.
4 For Pfix value, please modify "Replacement and fix value" inside panel "Pressure value
source settings".
5 For Tfix value, please modify "Replacement and fix value" inside panel "Temperature
value source settings".
6 Click "Write to device" in the toolbar.
7 Disable configuration mode, if required.
