20 FLOWSIC600-XT · Service Manual · 8019179/V0-2/2016-03 · © SICK Engineering GmbH
Components
Subject to change without notice
2.2.3 Ex-i enclosure version
Fig. 7 Exploded view Ex-i
1
2
3
4
5
6
1 Flameproof enclosure
2 Ex-d terminal compartment cover
3 Ex-i terminal compartment
4 Ex-i terminal compartment cover
5 Ex-i transducer electronics with cover and backup battery
6 Display unit
