38 FLOWSIC600-XT · Service Manual · 8019179/V0-2/2016-03 · © SICK Engineering GmbH
Repairs
Subject to change without notice
3.5.5 Replacing the SPU circuit board
Prerequisites
The display unit is swiveled down:
Swivel the display unit downwards, p. 31, §3.5.1.1.
The connection cables of the display unit and the connections for external power supply
and backup battery are disconnected:
Remove the display unit, p. 32, §3.5.1.2, step 1 and 2
3.5.5.1 Remove the electronics cover
1 Loosen the 4 screws of the electron-
ics cover with a T20 Torx key.
2 Take the electronics cover off.
