Operating Instructions
Laser Measurement Systems of the LMS500 Product Family
Chapter 1
1.4 Symbology used
Recommendation Recommendations are designed to give you assistance in the decision-making process with
respect to a certain function or a technical measure.
Important Sections marked “Important” provide information about special features of the device.
Explanation Explanations provide background knowledge on technical relationships.
M
E
NU
C
OMMAND
This typeface indicates a term in the SOPAS ET user interface.
Terminal output This typeface indicates messages that the LMS outputs via its interfaces.
Take action … Here you must do something. This symbol indicates an instruction to perform an action that
contains only one action or actions in warnings where a specific sequence does not need to
be followed. Instructions to perform actions that contain several steps in sequence are
numbered.
This symbol refers to additionally available documentation.
Software notes show where you can make the appropriate settings and adjustments in the
SOPAS ET configuration software.
Note!
A note indicates potential hazards that could involve damage or degradation of the
functionality of the LMS or other devices.
Warning!
A warning indicates an actual or potential hazard. They are designed to help you to prevent
accidents.
The safety symbol beside the warning indicates the nature of the risk of accident, e.g. due
to electricity. The warning category (DANGER, WARNING, CAUTION) indicates the severity of
the hazard.
Read carefully and follow the warning notices!
