Product description
38 © SICK AG · Division Auto Ident · Germany · Subject to change without notice 8013796/UL20/2010-09-27
Operating Instructions
Laser Measurement Systems of the LMS500 Product Family
Chapter 3
3.12 Planning
3.12.1 LMS system requirements
F
or commissioning and operating the LMS, the following are required:
• LMS500: Supply voltage DC 19.2 … 28.8 V, generated as per IEC 60364F4F41
(VDE 0100, part 410), output power minimum 24 W
•
LMS511: Supply voltage DC 19.2 … 28.8 V, generated as per IEC 60364F4F41
(VDE 0100, part 410), output power minimum 24 W.
Supply voltage for the heating DC 24 V, output power minimum 50 W (cyclic)
• Data interface RSF232/RS-422, Ethernet and USB (optional, in case several LMS are
connected together in a network)
• PC with operating system Windows 2000™, Windows XP™ or Windows Vista™ (see also
section 6.2.1 “System requirements for SOPAS ET” on page 58)
3.12.2 Mounting requirements
The LMS must be mounted as follows:
• robust
• as far as possible without shocks
• as far as possible without vibration
• protected from direct sunlight and heat sources
Mounting kits
The following mounting kits are available:
• mounting kit 1: mounting bracket for mounting at the rear on wall or machine (see
Fig. 49 on page 72)
• mounting kit 2: mounting bracket, only in conjunction with mounting bracket 1, cross-
wise adjustment possible (see Fig. 50 on page 73)
• mounting kit 3: mounting plate, only in conjunction with mounting bracket 1 and 2,
length-wise adjustment possible (see Fig. 51 on page 74)
• mounting with the Heavy Duty mounting bracket (see Fig. 51 on page 74)
Mount the LMS such that it is not exposed to direct sunlight (if necessary fit canopy). In this
way an inadmissible increase in the temperature inside the system is avoided.
