Operating Instructions
LMS500 Product Family
Product description
8013796/UL20/2010-09-27 © SICK AG · Division Auto Ident · Germany · Subject to change without notice 15
Chapter 3
3 Product description
This chapter provides information on the special features and properties of the LMS laser
measurement system. It describes the construction and the operating principle of the
device, in particular the different operating modes.
Please read this chapter before mounting, installing and commissioning the device.
3.1 Delivery
The LMS delivery includes the following components:
Section 10.3 “Ordering information” on page 95 provides an overview of the systems
available and the accessories available.
3.1.1 Contents of the CD-ROM
SOPAS ET configuration software
operating instructions “LMS500/511 Laser measurement system” in German and
English as PDF
freely available software “Adobe
®
Reader™”
The latest versions of the publications and programs included on the CDFROM are also
available for download at www.sick.com.
3.2 Device variants
The LMS comprises four components:
the housing
the sensor head with the opto-electronic acquisition system
the application module, this defines the functionality of the LMS
the system plug with the configuration memory (the system plug contains all electrical
connections)
Quantity Components Comment
1 An LMS laser measurement system LMS500-10000, LMS511-20100,
LMS511-10100, depending on order
1 Device instructions with electrical circuit
diagram for getting started
Is included in the LMS packaging
1 CDFROM “Manuals & Software Auto Ident” Contents see 3.1.1
Tab. 3: Delivery
Type Special features Range Heating Enclosure rating
LMS500-10000 Indoor variant max. 65 m
26 m @ 10%
1)
1) object remission
Without IP 65
LMS511-10100 Outdoor variant max. 65 m
26 m @ 10%
With IP 67
LMS511-20100 Outdoor variant max. 65 m
40 m @ 10%
With IP 67
Tab. 4: Device variants
