Troubleshooting
66 © SICK AG · Division Auto Ident · Germany · Subject to change without notice 8013796/UL20/2010-09-27
Operating Instructions
Laser Measurement Systems of the LMS500 Product Family
Chapter 8
8.3 Indications of the 7-segment display
8.4 Detailed error analysis
The LMS outputs occurring errors in various ways. Errors are output in stages and always
permit detailed analysis:
• Communication errors can occur on the transfer of messages to the LMS. The LMS then
returns an error code.
• In case of status errors occurring during a scan, error codes are written to a status log.
8.4.1 Field evaluation monitor
Using the field evaluation monitor, you can analyse whether and how evaluation fields are
infringed and how the outputs on the LMS behave.
PROJECT TREE, LMS…, MONITOR, FIELD EVALUATION MONITOR.
8.4.2 Field evaluation logging
Using the field evaluation logging you can log, save and subsequently play back the
operation of LMS. It is used for diagnostics over extended periods and for the analysis of
malfunctions or for the optimisation of processes.
PROJECT TREE, LMS…, MONITOR, FIELD EVALUATION LOGGING.
Display Possible cause Rectification of the error
, , …
No error Device in measurement mode
IDLE mode, the outputs are
in the OFF state, the laser is
switched off.
No error. If the criteria for the IDLE mode are
withdrawn, readiness for operation is re-
established.
Motor starts No error.
LMS faulty Send the LMS to the manufacturer for repair.
Tab. 19: Indications of the 7Fsegment display
