Operating Instructions
LMS500 Product Family
Technical specifications
8013796/UL20/2010-09-27 © SICK AG · Division Auto Ident · Germany · Subject to change without notice 73
Chapter 9
Fig. 50: Dimensional drawing, mounting kit 2
Scanner Mounting kit 1 Mounting kit 2
