Electrical installation
52 © SICK AG · Division Auto Ident · Germany · Subject to change without notice 8013796/UL20/2010-09-27
Operating Instructions
Laser Measurement Systems of the LMS500 Product Family
Chapter 5
5.4.3 Connecting the system plug on the LMS500
Reduced enclosure rating!
If the system plug is removed, the LMS500 are no longer compliant with the enclosure
rating IP 65. To prevent damage due to the entry of moisture and dirt, only open the
system plug in dry, clean surroundings.
If necessary, pre-wire and fit the adapter in suitable surroundings.
1. Ensure the power supply to which the LMS is connected is switched off.
2. Remove interface adapter on the underside of the device. For this purpose undo the
four fixing screws (Fig. 9.2.1 on page 70) and pull the adapter carefully off the device
perpendicular to the base.
3. The M16 cable entry (metal) has an earth connection to the device. If a screened
connecting cable is used, as necessary connect the screen braid on the cable to the
cable entry. For this purpose, shorten the screen braid as appropriate before
assembling the cable entry and fit over the plastic insert for the cable entry.
4. Undo fitting for the M16 cable entry.
5. Pull the cable for supply voltage and switching outputs with maximum outside diameter
10 mm (0,39 in) through the plastic insert for the M16 cable entry.
6. Connect electrically isolated wires to the terminal block.
7. If necessary, connect screen braid on the cable to the cable entry.
8. Fit M16 cable entry fitting and tighten.
9. Carefully re-fit the system plug to the LMS.
10. Tighten the fixing screws for the system plug.
