Annex
78 © SICK AG · Division Auto Ident · Germany · Subject to change without notice 8013796/UL20/2010-09-27
Operating Instructions
Laser Measurement Systems of the LMS500 Product Family
Chapter 10
10.2.2 Stop measurement
The LMS stops measuring.
Important The required user level is “Authorised client” (see section 10.2.7 “Select user level/login”
on page 87).
Request
Message structure: sMN LMCstopmeas
Answer
Message structure: sAN LMCstopmeas ErrorCode
Example
Request: <STX>sMN{SPC}LMCstopmeas<ETX>
HEX string: 02 73 4D 4E 20 4C 4D 43 73 74 6F 70 6D 65 61 73 03
Answer: <STX>sAN{SPC}LMCstopmeas{SPC}0<ETX>
HEX string: 02 73 41 4E 20 4C 4D 43 73 74 6F 70 6D 65 61 73 20 30 03
Message part Description Variable type Length
(byte)
Value range
Type of command Request (SOPAS method by name) string 3 sMN
Command Stop measurement string 11 LMCstopmeas
Message syntax III: Request “Stop measurement”
Message part Description Variable type Length
(byte)
Value range
Type of command Acknowledgement of receipt
(SOPAS answer)
string 3 sAN
Command Stop measurement string 11 LMCstopmeas
ErrorCode The command has been accepted
if the error code 0 is returned.
Enum8 1 0 no error
1 error, status change not
permitted
Message syntax IV: Answer to the “Stop measurement” request
