3 Product description
3.1 Type labels of the MLG-2 Prime
The MLG-2 senders and receivers each have a type label.
2
5
1
34
1110
4
7
6
5
9
3
2
1
8
Figure 1: Type label of sender
4
1 2
5
2
3
3
1
4
5
6
8
7
9
10 11 12
1 - brn - L+
2 - wht - Q
A1
3 - blu - M
4 - blk - C/Q1
5 - gra - Q
A2
Figure 2: Type label of receiver
1
Type code
2
Part number for the individual sender or receiver
3
Part number of the entire MLG-2
4
Receiver or sender symbol
5
Firmware version
6
Required power supply
7
Maximum output current
8
Serial number
9
2D matrix code, contains the order numbers of the sender/receiver, the order number of
the ML
G-2, and the serial number
ß
Diagram of the M12/5-pin male connector
à
Pin assignment of the M12/5-pin male connector
á
Pictogram diagram
3.2 Type code of the MLG-2 Prime
Example
MLG
-2 with 5 mm beam separation, type Prime, detection height 145 mm, 3 switching
outputs, no options, 5 m sensing range, as well as preconfiguration for object detection
and height classification
Table 2: Example of an MLG-2 Prime type code
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
M L G 0 5 S - 0 1 4 5 D 1 0 5 1 3
Table 3: Meaning of the positions in the type code
Position Meaning
1 … 3 Product family MLG
4 and 5 Beam separation 05 = 5 mm
10 = 10 mm
20 = 20 mm
25 = 25 mm
30 = 30 mm
50 = 50 mm
6 Type 0 = Special type
S = Pr
ime
3 PRODUCT DESCRIPTION
10
O P E R A T I N G I N S T R U C T I O N S | MLG-2 Prime 8018715.16YM / 2020-02-13 | SICK
Subject to change without notice
